Merlin Full Body Harness

The Merlin Full Body Harness has been designed for industrial rope access and technical rescue, where personnel wish to have either a wrap around or step in fit, with a pull over the head style.

The wrap around fit has been constructed into all the SAR multi purpose harness range. This innovative pattern includes two independent front waist attachment points in different profiles. This is so the rope access and rescue technicians can utilise any type of rope descender without twisting the system.

The Merlin is also fitted with upper ‘D’ connection points at the front and rear for safety back-up and fall arrest attachment. The laminated foam and shaped shoulder pads give additional comfort to the user.

The harness comes in two different forms, the standard Merlin or the Merlin Tech which has the addition of a fixed chest ascender. This gives an advantage to those who employ ‘frogging’ techniques for ascending.

Specifications:

1. Rated to: 150kg
2. Belay loop 30kN and ‘D’ connections 25kN
3. Double front attachments (Merlin 4 & 6 only)
4. One rear dorsal attachment. Fold away when not required
5. Two side attachments. Fold back when not required (Merlin 5 & 6 only)
6. Front fixed karabiner (standard Merlin Harness only)
7. Front fixed chest croll (Merlin Tech only)
8. 3 gear loops & 4 equipment rings
9. Quick clip buckles on leg loops (QC type only)
10. Slotted waist for fitting pouches, bolt bags or tool frogs
11. Laminated sandwiched closed cell foam padding
12. Shaped waist and legs for extra comfort
13. High quality polyester webbing
14. Fully adjustable waist and legs
15. Step in fitting or wrap around fitting
16. Waist circumference: Min 74cm – Max 114cm
17. Leg circumference: Min 48cm – Max 84cm
18. Weight – Merlin 6: 2.15kg

Product Codes:

Merlin Full Body Harness

Merlin 6: H0075

Merlin 5: H0074

Merlin 4: H0073

Merlin Tech Full Body Harness

Merlin 6: H0075T

Merlin 5: H0074T

Merlin 4: H0073T

Please note that the harness number denotes the number of attachment points.

Example: “Merlin 6” – features 6 attachment points
